Shanghai Bomar Industrial Co.,Ltd
10 Years
| Ask Lasest Price | |
| Brand Name : | XCMG |
| Certification : | CE, ISO9001 |
| Model Number : | QY16B.5 |
| Delivery Time : | 30 days |
| Payment Terms : | T/T or L/C at sight |
Dimension | Unit | QY16B.5 |
|---|---|---|
Overall length | mm | 12110 |
Overall width | mm | 2500 |
Overall height | mm | 3250 |
Weight |
|
|
Total weight in travel | kg | 24000 |
Front axle load | kg | 6400 |
Rear axle load | kg | 17600 |
Power |
|
|
Engine model |
| WD415.21 |
Engine rated power | kW/(r/min) | 155/2200,170/2200 |
Engine rated torque | N.m/(r/min) | 820/1400 |
Travel |
|
|
Max. travel speed | km/h | 75 |
Min. turning diameter | mm | 20000 |
Min. ground clearance | mm | 270 |
Approach angle | ° | 21 |
Departure angle | ° | 10 |
Max. grade ability | % | 24 |
Fuel consumption for 100km | L | ≤35 |
Main performance |
|
|
Max. rated total lifting capacity | t | 16 |
Min. rated working radius | m | 3 |
Turning radius at turntable tail | m | 3.14 |
Max. lifting torque | KN.m | 720 |
Base boom | m | 9.9 |
Fully extended boom | m | 31.1 |
Fully extended boom＋jib | m | 39.4 |
Longitudinal outrigger span | m | 4.6 |
Lateral outrigger span | m | 5.4 |
Working speed |
|
|
Boom luffing time | s | 60 |
Boom full extension time | s | 95 |
Max. swing speed | r/min | 2.5 |
Main winch full load/no load (single rope) | m/min | 54/100 |
Aux. winch full load/no load (single rope) | m/min | 54/100 |
|
|
